The MSI PRO Series motherboards are tailored to professionals from all walks of life. The lineup features impressive performance and high quality while aiming to provide users with an incredible experience. Users who care about productivity and efficiency can definitely count on the MSI PRO Series to assist you with multitasking and increasing efficiency. The MSI PRO Z790-P DDR4 is designed with tons of flexible tools for a productive and efficient experience.

Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation with a perfect fit. MSI motherboards let you manage speeds and temperatures for all your system and CPU fans in the BIOS and software with a simplified graphical interface. You can also set up to 4 temperature targets, which will adjust the fan speeds automatically.

FEATURES:

• Supports 12th/13th Gen Intel® Core™, Pentium® Gold and Celeron® processors for LGA 1700 socket
• Supports DDR4 Memory, Dual Channel DDR4 5333+MHz (OC)
• Enhanced Power Design_ 14+1+1 DRPS with 55A DrMOS, dual 8-pin CPU power connectors, Core Boost, Memory Boost
• Premium Thermal Solution_ Extended Heatsink, MOSFET thermal pads rated for 7W/mK, additional choke thermal pads and M.2 Shield Frozr
• High-Quality PCB_ 6-layer PCB made of 2oz thickened copper and server-grade level material
• Lightning Fast Game experience_ PCIe 5.0 slot, Lightning Gen 4 x4 M.2, USB 3.2 Gen 2x2
• Intel Turbo USB 3.2 Gen 2_ Powered by Intel USB 3.2 Gen2 controller
• 2.5G LAN_ Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
• Audio Boost_ Reward your ears with studio-grade sound quality for the most immersive gaming experience

SPECIFICATIONS:

• Socket: 1700
• CPU (Max Support): Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors
• Chipset: Intel® Z790 Chipset
• DDR4 Memory_ 5333/ 5200/ 5066/ 5000/ 4800/ 4600/ 4533/ 4400/ 4266/ 4000/ 3866/ 3733/ 3600/ 3466/ 3333MHz (O.C.)/ 3200/ 3000/ 2933/ 2800/ 2666/ 2400/ 2133 MHz (By JEDCE & POR)
• Memory Channel_ Dual
• DIMM Slots_ 4
• Max Memory (GB): 128
• PCI-E x16_ 3
• PCI-E X1_ 1
• SATAIII: 6
• M.2 Slot_ 4
• RAID: 0/1/5/10
• LAN: 1x Intel® 2.5Gbps LAN
• USB 3.2 ports (Front): 1(Gen 2, Type-C), 4(Gen 1, Type A)
• USB 3.2 ports (Rear): 1(Gen 2×2, Type-C), 1(Gen 2, Type A), 2(Gen 1, Type A)
• USB 2.0 ports (Front): 4
• USB 2.0 ports (Rear): 4
• Audio ports (Rear): Realtek® ALC897 Codec
• DisplayPort: 1
• HDMI: 1
• DirectX: 12
• Form Factor_ ATX
• Crossfire: Yes
• Operating System_ Support for Windows® 11 64-bit, Windows® 10 64-bit

WHAT'S IN THE BOX_

• MSI PRO Z790-P DDR4 LGA1700 ATX Gaming Motherboard - Black x1
• M.2 Clips x3
• I/O Sheild x1
• SATA Cables x2
• Driver DVD x1
• Quick Installation Guide x1
