The Antec DP502 FLUX White mid-tower gaming chassis is well equipped with an industry-leading design of advanced ventilation, taking the Antec Dark league gaming cases to the next generation.

To cope with the stress of enhanced heat dissipation, Antec developed a revolutionary structure for airflow, providing an improved and powerful cooling solution for your system. The F-LUX Platform. What is the F-LUX Platform? The definition of FLUX is Flow Luxury. The F-LUX Platform is a new industry-leading and highly efficient design by Antec featuring an advanced case structure for excellent airflow combined with 5 x 120 mm fans included. A core element of the design ethos was to enhance GPU cooling performance.

The electroplating-processed LED on the top left-hand side of the front panel presents a Sci-Fi vibe. The DP502 also comes with a 4mm thick tempered glass side panel. With a tool-free thumbscrew design at the rear of the tempered glass side panel, which gives you quick access to the interior, and enhances the solidity.

FEATURES:

• ATX | Micro-ATX | ITX support
• 3 x Front and 1 x Rear and 1 x PSU Shroud Fans Included
• 4 mm Tempered Glass Side Panel
• Sci-Fi Designed Vented Front Panel
• Built-in LED Controller
• USB3.0 and ARGB Control on I/O panel
• 405mm GPU support
• 175mm CPU cooler Support

SPECIFICATIONS:

• Materials: Steel | Plastic
• Dimensions: 46.3 x 22 x 48.6 cm
• Form Factor_ Mid-Tower
• Motherboard Support_ ATX, Micro-ATX, ITX
• I/O Ports_ Power, LED Control Button, 2 x USB3.0, HD-Audio
• Side Panel_ 4 mm Tempered Glass Side Panel
• Expansion & Drive Bays
  • Expansion Slots x7
  • 5.25" x1
  • 3.5"/2.5" (convertible) x3/2
  • 2.5" x3
• Fan Support_
  • Front 3 x 120mm / 2 x 140mm
  • Top 3 x 120mm / 2 x 140mm (w/o ODD and w/o ODD bracket), 2 x 120 mm / 2 x 140 mm (w/o ODD but with ODD bracket) 2 x 120 mm / 1 x 140 mm (When ODD is installed)
  • Power Supply Shroud 2 x 120mm
  • Rear 1 x 120mm
  • Included Fans 3 x 120mm fans in front, 1 x 120mm fan (Reverse Fan) on PSU shroud & 1 x 120mm fan in rear
• Radiator Support
  • Front ≤ 360mm (≤ 55 mm thickness when fans are installed outside of front panel) (≤ 30 mm thickness when fans are installed inside of front panel) [Max Radiator Length ≤ 405 mm]
  • Top ≤ 360mm (w/o ODD and  w/o ODD bracket) 240/280 mm (w/o ODD but with ODD bracket) 120 mm(When ODD is installed) [Max Radiator Length ≤ 405 mm]
  • Rear 120mm
• Clearance
  • Max GPU Length ≤ 405mm
  • Max CPU Cooler Height ≤ 175mm
  • Max PSU Length ≤ 205mm
• Dust Filters_ Front/Top/Bottom/Right Hand Side
• Weight: 7550 g

WHAT’S IN THE BOX_

• Antec DP502 FLUX White ATX Mid-Tower Gaming Chassis x1
