With an increase in core count, Intel 13th Gen processors continue to utilize Intel’s performance hybrid architecture to optimize your gaming, content creation, and productivity. Leverage industry-first bandwidth of up to 16 PCIe 5.0 lanes and DDR5 memory up to 5600 MT/s. Supercharge your CPU performance with a powerful suite of tuning and overclocking tools. Enjoy your favourite experiences in up to 4 simultaneous 4K@60Hz displays or up to 8K@60Hz HDR Video with dynamic noise suppression. Support for the Intel® 700 series chipsets and backward compatibility with the Intel® 600 series chipsets allow you to access the features you need for any task. Whether you are working, streaming, gaming, or creating, the 13th Gen Intel® Core™ desktop processors deliver the next generation of breakthrough performance.

The 13th Gen Intel® Core™ desktop processors deliver the next generation of breakthrough core performance. Meanwhile, additional E-cores enable an increase in Intel® Smart Cache (L3) for more efficient processing of larger data sets and better performance. The P-core and E-core L2 cache has also increased compared to the previous generation of Intel® processors, minimizing the amount of time spent swapping data between cache and memory to speed up your workflow. Unleash the power of next-level performance with the 13th Gen Intel® Core™ desktop processor advantage.

FEATURES:

• 24 Cores
• 32 Threads
• Max Turbo Frequency of up to 5.60GHz
• 36MB Intel® Smart Cache
• Support for DDR4 and DDR5 memory
• Built for serious gaming
• Smart solutions for enthusiasts and creators

SPECIFICATIONS:

• Essentials:
  • Product Collection_ 13th Generation Intel® Core™ i9 Processors
  • Code Name_ Products formerly Raptor Lake
  • Vertical Segment_ Desktop
  • Processor Number_ i9-13900
• CPU Specifications_
  • Total Cores_ 24
  • # of Performance-cores: 8
  • # of Efficient-cores: 16
  • Total Threads_ 32
  • Max Turbo Frequency_ 5.60 GHz
  • Intel® Thermal Velocity Boost Frequency_ 5.60 GHz
  • Intel® Turbo Boost Max Technology 3.0 Frequency_ 5.50GHz
  • Performance-core Max Turbo Frequency_ 5.20 GHz
  • Efficient-core Max Turbo Frequency_ 4.20 GHz
  • Performance-core Base Frequency_ 2.00 GHz
  • Efficient-core Base Frequency_ 1.50 GHz
  • Cache: 36 MB Intel® Smart Cache
  • Total L2 Cache_ 32 MB
  • Processor Base Power_ 65 W
  • Maximum Turbo Power_ 219 W
• Memory Specifications_
  • Max Memory Size (dependent on memory type): 128 GB
  • Memory Types_ Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s
  • Max # of Memory Channels_ 2
  • Max Memory Bandwidth_ 89.6 GB/s
  • ECC Memory Support_ Yes
• Processor Graphics_
  • Processor Graphics_ Intel® UHD Graphics 770
  • Graphics Base Frequency_ 300 MHz
  • Graphics Max Dynamic Frequency_ 1.65 GHz
  • Graphics Output_ eDP 1.4b, DP 1.4a, HDMI 2.1
  • Execution Units_ 32
  • Max Resolution (HDMI): 4096 x 2160 @ 60Hz
  • Max Resolution (DP): 7680 x 4320 @ 60Hz
  • Max Resolution (eDP – Integrated Flat Panel): 5120 x 3200 @ 120Hz
  • DirectX* Support_ 12
  • OpenGL* Support_ 4.5
  • OpenCL* Support_ 3.0
  • Multi-Format Codec Engines_ 2
  • Intel® Quick Sync Video_ Yes
  • Intel® Clear Video HD Technology_ Yes
  • # of Displays Supported_ 4
  • Device ID_ 0xA780
• Expansion Options_
  • Direct Media Interface (DMI) Revision_ 4.0
  • Max # of DMI Lanes_ 8
  • Scalability: 1S Only
  • PCI Express Revision_ 5.0 and 4.0
  • PCI Express Configurations_ Up to 1×16+4, 2×8+4
  • Max # of PCI Express Lanes_ 20
• Advanced Features_
  • Intel® Gaussian & Neural Accelerator_ 3.0
  • Intel® Thread Director_ Yes
  • Intel® Deep Learning Boost (Intel® DL Boost): Yes
  • Intel® Speed Shift Technology_ Yes
  • Intel® Thermal Velocity Boost_ Yes
  • Intel® Turbo Boost Max Technology 3.0: Yes
  • Intel® Turbo Boost Technology_ 2.0
  • Intel® Hyper-Threading Technology_ Yes
  • Intel® 64_ Yes
  • Instruction Set_ 64-bit
  • Instruction Set Extensions_ Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
  • Idle States_ Yes
  • Enhanced Intel SpeedStep® Technology_ Yes
  • Thermal Monitoring Technologies_ Yes
  • Intel® Volume Management Device (VMD): Yes
• Security & Reliability
  • Intel® Standard Manageability (ISM): Yes
  • Intel® Control-Flow Enforcement Technology_ Yes
  • Intel® AES New Instructions_ Yes
  • Secure Key_ Yes
  • Intel® OS Guard_ Yes
  • Intel® Trusted Execution Technology_ Yes
  • Execute Disable Bit_ Yes
  • Intel® Boot Guard_ Yes
  • Mode-based Execute Control (MBEC): Yes
  • Intel® Virtualization Technology (VT-x): Yes
  • Intel® Virtualization Technology for Directed I/O (VT-d): Yes
  • Intel® VT-x with Extended Page Tables (EPT): Yes

WHAT’S IN THE BOX_

• Intel 13th Gen Core i9-13900 LGA1700 2.00GHz 24-Core CPU x1
